Description
Quarters
Variable Load
106 persons
6,640.57 kips
Drawworks
Pumps
Lewco LDW 1500 K 4,500 hp
(3) Triplex Lewco model W-2215, 2.200 hp
each; driven by two OEMTT1150 AC
electric vector motor each.
Lewco model LR100/120; 100,000 ft-lb
make-up torque capacity and 120,000 ft-lb
breakout torque capacity.
P-Tank (Barite) 6,240 cu ft Iron Roughneck
P-Tank
(Cement)
Liquid Mud
Potable Water
6,240 cu ft
4,929 bbls
1,625 bbls
13,758 bbls
Drill Water
Diesel Fuel
Base Oil
Storage
2,162 bbls
1,070 bbls
Main Power
Cranes
Lewco model TB-750 750 kips
Lewco Model 750, 750 tons capacity
Loadmaster 170′ x 35′ x 32′
Total Salt
Water (P/load)
Chemical/Sack
Storage
Tubular Storage
(Cantilever)
49,772 bbls
121 m2
750 ton
Mud Cleaner
Shakers Drillers
Control
Five (5) Caterpillar Model 3516B diesel
with a total of 10,750 BHP, radiator cooled.
Each driving an AC Kato, 1,540 Kw
generator
Three LeTourneau, marine type; two of
them model
PCM-120-SS with a load capacity of
100,000 lb; one of them model PCM
220SS with a load capacity of 110,340 lb.
One LCM-3D/CMC(32/0) Brandt linear
motion Mud conditioner, 32 desilter cones
of 4” diam.
Five LCM-3D/CM-2 Brandt linear motion
shale shakers.
Cabin totally pressurized and air
conditioned to control the OEM ACIS
(Automatic Control Integration System)
drilling system, with one ergonometric
chair to attend all different drilling
operations.
